Came VER 10 – automatic garage door opening kit

VER 10 – automatic garage door opening kit.
Advantages:
- Ver operators are supplied with 24-V voltage for complete safety,
- the motor automatically detects obstacles when the door is closing,
- slowdown during closing,

The VER 10 kit includes the following components:
- 24 V operator with encoder,
- frequency card,
- available remote control types: Top (2-channel) or Space (2-channel),
- drive rail not included,
- the operator must be purchased complete with the drive rail in order for the kit to be ready for installation.

Specification:

- door area of up to 18 m2,
- maximum motor power: 130 W,
- opening time of up to 6 m/min,
- duty cycle: 50%, residential,
- thrust: 1000 N,
- operating temperature: -20°C to +55°C.

Standard functions:
- amperometric obstacle detection adjustable with a trimpot,
- a lamp can be connected to illuminate the garage,
- endstops integrated into the operators enable quick and accurate adjustment of opening and closing points,
- door stopping with the remote control,
- safety even when the door is not moving thanks to the special electronic circuit which ignores every command if an obstacle is detected by the safety devices.

Additional functions:
- emergency power supply after the VO670 card is connected.

Instructions in the link.
